* LED banners can be added in many different configurations to most eBlimp RC Airships.

1) the Matrix can be adjusted for your needs. a matrix can be arranged in a long low profile sign if you desire to display only words,

2) a more rectangular profile if you desire to show words and logos,

3) a more squarish screen if you prefer to show Video. 16x9, or 4x3 or any other dimensions you like are possible.

4) up to 16,000 LEDS - or more...

* LED files Can be preprogrammed and saved to an SD card, Or an optional transmitter can be purchased to transmit live video during flight.

* We have a new unique programamble LED system that is custom engineered to be lighterweight than anything else available; as little as 0.1 grams per LED!

* Costs start at $1 per pixel.

* Please check our videos for samples, more videos will be posted in the future, so please check back.

LED signs are an available upgrade on almost any RC blimp

The Video shown here is an e700B500 (5 meter) outdoor RC Zeppelin with a 75 x 14 matrix, totaling 1050 pixel on each side of the blimp. These are our larger & brighter pixels witha large pitch spacing of ony 30 pixel per meter, making the screen a very large 2.5meters long x .47 meters tall. the supporting blimp is an e700B500 model. This complete system would sell for $8900 with a single sided LED matrix, or $9900 with the (2) sided matrix.

1050 LED; 75 x 14 Matrix

The Video shown here is an e700B500 (5 meter) outdoor RC Zeppelin with a 96 x 21 matrix, totaling 2016 pixel on each side of the blimp. These are our brighter heavier pixels witha medium pitch spacing of ony 48 pixel per meter, making the screen a large 2 meters long x .44 meters tall. the supporting blimp is an e700B500 model. This complete system would sell for $10,400 with a single sided LED matrix, or $12,400 with the (2) sided matrix.

2016 LED; 96 x 21 Matrix

The Video shown here is a 60 x 16 matrix, totaling 960 pixel on each side of the blimp. These are our brighter heavier pixels with a smaller pitch spacing of 60 pixel per meter, making the screen fairly small 1 meters long x .27 meters tall. the supporting RC blimp is an e200B400i model. This complete system would sell for $6820 for the system with a (2) sided matrix.

960 LED; 60 x 16 Matrix

The Video shown here is a 64 x 36 matrix, totaling 2048 pixel on each side of the blimp. These are our brighter heavier pixels with a medium pitch spacing of 48 pixel per meter, making the screen fairly large 1.3 meters long x .67 meters tall. the supporting Remote Control blimp is an e300B450i model. This complete system would sell for around $9500 for the system with a (2) sided matrix.ee

2048 LED; 64 x 36 Matrix

indoor eBlimps suggested LED count

e100 series:

2.5 meter: 210 led each side; 30 x 7 text only, all caps.

3 meter:780 led each side; 60 x 13 standard text; or 30x26 logos.

4 meter: 2040 led each side; 120 x 17 standard text; or 60x34 logos and video.

e200 / 300 series:

3 meter: 210 led each side; 30 x 7 text only all caps.

4 meter: 900 led each side; 60 x 15 standard text; or 30x30 logos.

5 meter: 2048 led each side; 120 x 17; standard text, 72 x 28 or 64 x 32 logos & video

e700 series:

5 meter: 2048 led each side; 120 x 17 standard text; 72 x 28 or 64 x 32 logo and video

6 meter: 8192 led each side; 300 x 27 standard text; 120 x 68 or 90 x 90 logo and video.

Outdoor eBlimps suggested LED count

e300 series:

3.5 meter: 600 led each side; 45 x 13 text only, 30 x 20 logos

4 meter: 1350 led each side; 90 x 15 standard text; or 45 x 30 logos and video.

e700 series

4.5 meter: 1350 led each side; 90 x 15 standard text; or 45 x 30 logos and video.

5 meter: 2048 led each side; 120 x 17; standard text, 72 x 28 or 64 x 32 logos & video

e1000 series:

6 meter: 1440 led each side; 96 x 15 standard text; or 48 x 30 logos.

7 meter: 2048 led each side; 128 x 16 standard text; 64 x 32 logo and video.

8 meter: 4096 LED each side; 192 x 21 standard text & logos, 120 x 68 Logos and video

e2000 series

11 meter: 8192 led each side; 300 x 27 text & logos; 120 x 68 or 90 x 90 logo and video.

12 meter: 16000 led each side; 384 x 41 text & logos; 150 x 100 logo and video.

LED matrix guidelines.

Nothing in the blimp world is absolute black and white. Everything has room for customization. Due to our manufacturing methods, LEDs matrixes will be most cost effective if the lengthwise dimension is a multiple of 12, 15, or 25, LEDS in length.

As an approximated rule, here are some estimates for how many LEDS our blimps should be set up to carry in a matrix...
